The SANY SCC1000A-6 crawler crane is a high-performance 100-ton lattice boom crawler crane designed for demanding lifting operations in construction and infrastructure projects. Featuring a strong structural design, advanced control systems, and efficient power performance, this crane delivers reliable lifting capacity and excellent stability in complex jobsite environments.
With a maximum lifting capacity of 100 tons and a maximum lifting moment of 396 t·m, the SCC1000A-6 provides powerful lifting performance for a wide range of heavy-duty applications. The crane’s modular lattice boom system, with a maximum boom length of 64 meters, allows flexible configuration for different lifting requirements.
Designed with intelligent control technology and user-friendly operation systems, the SCC1000A-6 ensures improved safety, efficiency, and operator comfort, making it an ideal lifting solution for modern construction projects.
Technical Specifications (Typical / Reference)
| Parameter | Specification |
|---|---|
| Model | SANY SCC1000A-6 |
| Crane Type | Lattice Boom Crawler Crane |
| Maximum Lifting Capacity | 100 t |
| Maximum Lifting Moment | 396 t·m |
| Main Boom Length | 13 – 64 m |
| Fixed Jib Length | 9 – 18 m |
| Longest Boom + Jib | 52 m + 18 m |
| Boom Luffing Angle | 0 – 80° |
| Engine Model | Weichai WP7 |
| Engine Power | 199 kW / 2300 rpm |
| Main & Auxiliary Winch Speed | Up to 130 m/min |
| Boom Hoist Winch Speed | Up to 70 m/min |
| Maximum Travel Speed | 1.5 km/h |
| Gradeability | 30% |
| Counterweight | 33 t rear counterweight |
| Average Ground Pressure | 0.092 MPa |
Key Features
Powerful Lifting Performance
The SCC1000A-6 crawler crane delivers outstanding lifting capability with a rated lifting capacity of 100 tons and a maximum lifting moment of 396 t·m. Its optimized structural design provides strong load-handling performance and ensures stable lifting even in demanding construction environments.
Flexible Boom Configuration
The crane is equipped with a lattice boom system ranging from 13 m to 64 m, allowing flexible configuration according to project requirements. A fixed jib of 9–18 m can also be installed, extending the working range for high-reach lifting operations.
Efficient Power System
Powered by a reliable WEICHAI WP7 diesel engine, the crane provides 199 kW of rated power at 2300 rpm, ensuring stable performance and fuel efficiency during long operating cycles.
Intelligent Control System
The SCC1000A-6 features an advanced SYIC-II integrated control system, which provides precise operation control, real-time monitoring, and intelligent diagnostics. The system improves operational safety and enhances crane productivity on site.
Easy Transportation and Assembly
With modular structural components and optimized transport dimensions, the crane can be transported efficiently between job sites. Its self-assembly and self-disassembly design helps reduce setup time and lowers transportation costs.
Comfortable Operator Cabin
The ergonomically designed operator cabin provides a comfortable working environment with improved visibility and intuitive control interfaces. The touchscreen display system allows operators to easily monitor machine status and lifting conditions.
Typical Applications
The SANY SCC1000A-6 crawler crane is widely used in various heavy lifting and construction projects, including:
- Infrastructure construction
- Bridge and highway projects
- Steel structure installation
- Petrochemical plant construction
- Wind power equipment installation
- Industrial equipment lifting
Thanks to its strong lifting capacity and flexible boom configuration, the SCC1000A-6 can handle complex lifting operations across a wide range of industries.
